Specifications
|
|
Rated Output Power: |
300 Watts at 8 Ohms
600 Watts at 4 Ohms
|
|
Frequency Response: |
+/- 0.1 dB from 10 Hz to 20 kHz |
|
Signal-to-Noise Ratio: |
-110 dB, reference level: full power output |
|
Total Harmonic Distortion (THD): |
<0.02% at 1 kHz, at 300 W, 8 Ohms
<0.05% at 20 kHz, at 300 W, 8 Ohms
|
|
Gain: |
22 dB |
|
Input Impedance: |
50k Ohms (single-ended)
100k Ohms (balanced) |
|
Damping Factor: |
250, reference 8 Ohms nominal |
|
Power Consumption: |
550 Watts idle, 1,800 watts maximum |
|
Inputs: |
2 balanced via XLR connector (1 per channel)
2 single-ended via RCA connector (1 per channel) |
|
Outputs: |
4 pairs WBT binding posts (2 pairs per channel)
|
|
Operating Voltage: |
100V, 120V, 220V, 230V or 240V at 50 or 60 Hz |
|
Dimensions: |
19 in. W x 9.5 in. H x 27 in. D |
|
Weight: |
160 lbs. |
|
Warranty: |
3 Years Parts and Labor |
